CL-2094 Architectural LED Fixture – Exterior & Interior Lighting for Hotels, Restaurants, & Commercial Spaces

CL-2094 Architectural LED Fixture – Exterior & Interior Lighting for Hotels, Restaurants, & Commercial Spaces

HLCL-2094-S

The CL-2094 Architectural LED Fixture combines modern design with high-performance lighting, making it ideal for hotels, restaurants, public transportation facilities, and commercial exteriors. Featuring a pyramid top with geometric overlays on a frosted acrylic lens, this fixture delivers both style and functionality.

Available in small, medium, and large sizes, the CL-2094 provides flexible installation options including Post Top, Arm Mount, and Sconce. Constructed from heavy-gauge aluminum and finished in multiple powder-coated colors, it’s engineered to withstand damp and wet locations while providing long-lasting LED performance.

With optional features like motion sensors, photocells, and emergency battery packs, the CL-2094 offers energy-efficient lighting solutions with minimal maintenance, backed by a 10-year or 10,000-hour limited warranty.

Key Features:

  • Architecturally designed LED fixture with pyramid top and geometric overlay
  • Heavy-gauge aluminum housing with frosted acrylic lens
  • 120/277V multi-volt driver with high-efficiency Lumileds LEDs
  • Color temperatures: 3000K, 4000K, 5000K
  • CRI: 70+
  • UL listed for damp and wet locations
  • Optional features: Button photocell, microwave motion sensor, emergency battery pack
  • Multiple finishes: Matte Black, Glossy Black, Texture Black, Texture White, Silver, Bronze, Graphite
  • Installation types: Post Top, Arm Mount, Sconce
  • Rated life (L70) > 200,000 hours
  • 10-year or 10,000-hour limited warranty

Specifications by Model & Size:

Post Top Mount:

Model Size Wattage Lumen Output LPW Voltage Finish Dimensions (A×B) Options
CL-2094S Small 5W – 10W 918 – 1,914 lm 183 – 191 120-277V MBLK, GBLK, TBLK, TWHT, SLR, BRZ, GPH 10” × 6” Photocell (PC)
CL-2094M Medium 20W – 25W 2,754 – 2,935 lm 146 – 183 120-277V Same as above 12” × 8” Motion Sensor (MWS), Emergency Battery (EMR)
CL-2094L Large 30W – 40W 4,842 – 6,252 lm 152 – 161 120-277V Same as above 15” × 10” Motion Sensor (MWS), Emergency Battery (EMR)

Arm Mount:

Model Size Dimensions (A×B×C)
CL-2094S Small 10” × 6” × 8”
CL-2094M Medium 12” × 8” × 10”
CL-2094L Large 15” × 10” × 12”

Sconce Mount:

Model Size Dimensions (A×B×C)
CL-2094S Small 10” × 6” × 3”
CL-2094M Medium 12” × 8” × 4”
CL-2094L Large 15” × 10” × 5”
