JANUS Series Architectural LED Post Mount Light – IP65/IP67 Outdoor Area Luminaire (20W–100W)

The JANUS Series Architectural LED Lighting Post Mount fixture combines timeless design with advanced LED performance for modern outdoor applications. Designed for wet locations, this versatile luminaire is ideal for residential exteriors, walkways, perimeters, school campuses, commercial properties, industrial facilities, parking lots, and recreational parks.

With wide light distribution and high-efficiency Lumiled LEDs, the JANUS Series delivers powerful, uniform illumination while reducing energy consumption by over 66% compared to traditional HID fixtures. Built for durability, this fixture features corrosion-resistant aluminum construction, a 3-mil powder coat finish, and IP65/IP67-rated protection for long-term outdoor reliability.

Available in multiple shades, wattages, mounting options, and finishes, the JANUS Series provides design flexibility without compromising performance.

Backed by a 10-Year / 100,000-Hour Limited Warranty.

Key Features

• Architectural LED post mount luminaire
• Suitable for wet locations (IP65 / IP67 rated)
• Wide light distribution for large outdoor areas
• Over 66% energy savings vs. HID lighting
• High-efficiency Lumiled LEDs
• Excellent lumen maintenance (L70 > 200,000 hours)
• 0–10V dimming capable
• Optional occupancy sensor, photocell, and wireless controls
• Corrosion-resistant aluminum housing
• 3 mil powder coat finish
• Frosted acrylic lens (standard)
• Optional opal acrylic lens
• Operating temperature: -30°C to 60°C
• 120–277V standard driver, 480V optional
• 10-Year / 100,000-Hour Limited Warranty

Ideal Applications

• Residential communities
• Walkways and pathways
• School campuses
• Parking lots
• Commercial buildings
• Industrial sites
• Parks and recreational spaces
• Perimeter security lighting

General Specifications

• Wattage Options: 20W, 30W, 50W, 60W, 80W, 100W
• Light Distribution: Type III (T3) or Type V (T5)
• Color Temperatures: 3000K / 4000K / 5000K
• CRI: 70+
• Voltage: 120–277V (standard) or 480V (optional)
• Mounting: 3” O.D. Tenon or Pole (adapter required for other sizes)
• Mount Options: Round or Square (3” SQ, 4” SQ, 3” OD, 4” OD)
• Finish Options: Black, White, Bronze, Silver, Graphite, Marine Grade
• Shade Options: Shade 1 (SH1), Shade 2 (SH2)

Dimensions

• JANUS Small – Shade 1 (JNS-S-SH1)
  • Height (A): 21”
  • Width (B): 13 3/16”
  • EPA: 0.98
• JANUS I – Shade 1 (JNS-I-SH1)
  • Height (A): 26 1/2”
  • Width (B): 20”
  • EPA: 1.34
• JANUS I – Shade 2 (JNS-I-SH2)
  • Height (A): 26 1/2”
  • Width (B): 20”
  • EPA: 1.36

• Performance Specifications by Model
• JNS-S/1-20CLED
  • Input Power: 25W
  • Lumen Output: 3,650 lumens
  • Efficacy: 182 LPW
  • HID Equivalent: 100W Metal Halide
• JNS-S/1-30CLED
  • Input Power: 35W
  • Lumen Output: 5,509 lumens
  • Efficacy: 183 LPW
  • HID Equivalent: 150W High Pressure Sodium
• JNS-1-50CLED
  • Input Power: 55W
  • Lumen Output: 7,780 lumens
  • Efficacy: 155 LPW
  • HID Equivalent: 250W Metal Halide
• JNS-1-60CLED
  • Input Power: 65W
  • Lumen Output: 8,539 lumens
  • Efficacy: 142 LPW
  • HID Equivalent: 250W Pulse Start Metal Halide
• JNS-1-80CLED
  • Input Power: 85W
  • Lumen Output: 9,986 lumens
  • Efficacy: 142 LPW
  • HID Equivalent: 250W High Pressure Sodium
• JNS-1-100CLED
  • Input Power: 105W
  • Lumen Output: 14,640 lumens
  • Efficacy: 120 LPW
  • HID Equivalent: 400W Pulse Start Metal Halide

• Available Options
• Occupancy Sensor (OCC)
• Button Photocell (PC)
• Wireless Controls (WC)
• Opal Acrylic Lens (OAL)
• External Mount Option
• 480V Driver
• Marine Grade Finish

• Why Choose JANUS Series?
• The JANUS Series offers architectural elegance, rugged outdoor durability, and high-efficiency LED performance in one versatile post mount solution. With multiple shade designs, mounting configurations, and advanced control capabilities, it is an excellent choice for municipalities, campuses, commercial developments, and residential communities seeking dependable outdoor LED lighting.
